Cleaning instructions

The cleaning guide is available at the link above.

To keep your Airblade looking new, ensure that all surfaces of the Airblade hand dryer are cleaned daily with a soft cloth and a nonabrasive/non-caustic cleaning solution.

Wipe down the fascia daily to avoid mineral deposits and build up of debris. Clean the floor and wall beneath and around the unit. This may be required more regularly in high use areas.

The following chemicals are some that are harmful to the unit and should not be used. The use of these will invalidate the warranty.

Do not use:

• Alcohol-acid mixes
• Alcohol
• Solvent / oil-based products
• Quaternary ammonium
• Alkali-bleach mixes
• Foaming ingredients
• Bleach or abrasive cleaners
• Do not pressure wash

Cleaning instruction - Wipe inside

Cleaning instruction - Wipe base

Cleaning instruction - Wipe the floor

Changing the filter

Replacement parts for your hand dryer can be carried out by carefully following the instructions given in the replacement pack and installation guide. If in any doubt, consult a qualified electrician or contact the Dyson Helpline for support.

Remove the two screws in the door at the base of the unit and remove the door.

Release the HEPA filter from the release catch on the side.

Ensure the larger retainer on the right hand side of the replacement HEPA filter locates into the slot in the base of the motor bucket assembly.

Once located, ensure the small retainer on the left hand side locates into the release catch.

Refit the door and the two screws.

Replacement parts for your hand dryer can be carried out by carefully following the instructions given in the replacement pack and installation guide. If in any doubt, consult a qualified electrician or contact the Dyson Helpline for support.

Fascia replacement

Carefully replace the fascia as illustrated. Do not trap the electrical wiring when attaching the fascia. Make sure that the clips on top of the front fascia are seated correctly.

Make sure that the fascia is mounted flush. Insert and tighten the 2 anti-tamper screws into the middle of the fascia as illustrated.

In the lower rear corner of the fascia place a mounting nut into the mounting hole. Hold it in place with your hand or an 8mm Allen key. Then insert an anti-tamper screw into the front of the fascia. Tighten with the service tool. Repeat the process for the opposite lower side.

Ensure the washer door is fixed onto the Airblade and is in the closed position.

Insert the anti-tamper screws and tighten with the service tool.

Test the unit for correct operation before affixing the 2 fascia caps.

Please note: this product will generate some warming of the air when used constantly in busy locations. This will appear in high ambient air temperature, or when drawing hot air from a localised heat source. This is normal.

No problem with the machine

This would indicate that the machine is working as intended.

Please check the Air knives and inspect for external blockages.

Please switch the power supply on and off and retest the machine.

Ensure you have checked RCD unit. (Residual Current Device / Trip switch).

Check that other appliances in the room are working, such as lights.

Problems with electrical supply is not related to Airblade and should be resolved by an electrician.

An electrician will be required to proceed with the next steps.

Problems with electrical supply is not related to Airblade and should be resolved by an electrician.

Check reflective surfaces and light source

Please note that any changes to the bathroom environment such as installation of new lighting, mirrors or other surfaces which can cause a reflective in the direction of the sensor points can cause an intermittent issue with the machine.

To rule out the above, please switch the lights off and block out any external light source.

Retest the machine and move onto the next step.

In addition, please check the installation guide to ensure the machine has been fitted in the correct location.

Please clean the 4 lenses with a non-abrasive cloth and cleaning solution.

Please clean the 4 lenses with a non-abrasive cloth and cleaning solution.

Cleaning instructions

The following chemicals are some that are harmful to the unit and should not be used. The use of these will invalidate the warranty.

Warning: Do not use:

Alcohol-acid mixes
Alcohol
Solvent / oil-based products
Quaternary ammonium
Alkali-bleach mixes
Foaming ingredients
Bleach or abrasive cleaners
Do not pressure wash

WARNING: Do not pressure wash

Damage caused by air fresheners will be covered on the first instance and chargeable thereafter.

Please proceed to clean the product under the Dyson guidelines.

To keep your Dyson Airblade™ hand dryer looking new, ensure that all surfaces of the Dyson Airblade™ hand dryer are cleaned daily with a soft cloth and a non-abrasive, non-caustic cleaning solution.

Wipe down the fascia daily to avoid mineral deposits and build up of debris. Clean the floor and wall beneath and around the unit. This may be required more regularly in high-use areas.

Some chemicals are harmful to the unit and must not be used. Using them will invalidate the warranty.

Warning: Do not use:

Alcohol-acid mixes
Alcohol
Solvent / oil-based products
Quaternary ammonium
Alkali-bleach mixes
Foaming ingredients
Bleach or abrasive cleaners
Do not pressure wash

Damage caused by air fresheners will be covered on the first instance and chargeable thereafter.

Flow lines occur during production and are a result of the plastic moulding process. This is perfectly normal and will not impact on the function or structure of the machine.

Please note that when using our product (and any other hands under, wall mounted hand dryer) that the water from wet hands is blown off into the air and if there is a collection of water on the wall, this can be easily wiped away as part of the regular cleaning regime in the washroom.

If the water on the wall is an issue, especially for porous surfaces, consider the use of a splash back or non-porous wall surface (e.g. ceramic tile).
