The engineering story

Fluorescent lighting is flawed. LEDs can be misused.

Commercial lighting largely relies on inefficient, costly fluorescent bulbs or the ineffective use of multiple LEDs. Light is spilled and wasted in all directions. The blanket of bright light can strain people’s eyes, causing avoidable discomfort.

How to buy

Call us 855-720-6378
Request a meeting
LEDs

LEDs can last a lifetime. But they're not cool enough.

Lighting technology typically means LEDs can’t last as long as they’re able to. Not cooling them properly leads to overheating, which damages brightness and longevity. Using multiple, smaller LEDs isn’t the answer either. Quantity doesn’t make for quality.

Laptop computer parts

Finding coolness, from the inside out.

We started with the LED itself rather than its output. Like any semiconductor, LEDs need properly cooling to optimize their performance. So we reapplied the cooling technology used in satellites in the 1960s, and the heat sinks used ubiquitously to cool fridges and computers.

Watch the video Jake Dyson explains heat pipe technology

Heat pipe technology effectively dissipates heat.

Getting heat away from the LEDs quickly, was key. Heat pipes use a small amount of water to spread heat. We used just a single drop in each vacuum-sealed copper tube. Copper worked best because it conducts heat so well, while the vacuum reduces the water’s boiling point.

PLAY
Heat pipe technology illustration

Continuous evaporation and condensation keeps the LEDs cool.

The difference in pressure in the vacuum means the vapor evaporates and moves along the tube. When it cools via 37 aluminum fins, it condenses, before being drawn back to the LEDs via capillary action along a copper wick. The cycle then repeats in a continuous loop.

Prototype lenses

Custom-engineered lens. For precise up-light.

The efficient distribution of light also required the right optics. It's why we custom design, test and manufacture them all in-house. Through rigorous design, analysis, and prototyping, including minute changes to geometry and texture, the lenses we developed get the best from the LED.

Cu-Beam Up light on white

Cu-Beam Up light.

Cooled by Heat pipe technology, a single high-power LED projects a wide pool of even, ambient light. Fully adjustable to fulfil any task, Cu-Beam Up light can maintain LED brightness for up to 180,000 hours.¹

Cu-Beam Duo light

Cu-Beam Duo logo

Fully flexible up and down-light.

Heat pipe technology Cools the LED to sustain brightness
Weight 7lbs
Output Combined output of 9400 lumens (at 4000K)

Fully flexible up and down-light.

Heat pipe technology Cools the LED to sustain brightness
Weight 7lbs
Output Combined output of 9400 lumens (at 4000K)

Cu-Beam Down light

Cu-Beam Down logo

Powerful, focused down-light. From one LED.

Heat pipe technology Cools the LED to sustain brightness for up to 180,000 hours¹
Weight 6.56lbs
Output One LED provides 5200 fixture lumens (at 3000K)

Powerful, focused down-light. From one LED.

Heat pipe technology Cools the LED to sustain brightness for up to 180,000 hours¹
Weight 6.56lbs
Output One LED provides 5200 fixture lumens (at 3000K)

Next

Cu-Beam Up light at work

How to buy

Call us 855-720-6378
Request a meeting
Podium of Dyson products beneath Cu-Beam light

See how Dyson technology can improve your business environment

¹Calculated lifetime based on LED L70.
